Best Timing Belt Kit: How to Choose the Right One

Timing belt and pulleys at the front of an engine

A timing belt is a wear part with a strict replacement interval, and on many engines a failure can bend valves. When the belt is due, most mechanics replace it as a kit rather than the belt alone.

Kits are made for specific engines, so the best kit is the right kit for yours from a reputable maker. This guide explains what to look for and how to avoid common installation mistakes.

What you’ll learn

  • What a timing belt kit includes
  • Kit with or without a water pump
  • How to choose a quality kit
  • Key installation tips
EngineBuying guideTiming

Quick answer

The best timing belt kit is one made for your exact engine (check by engine code or VIN) from an established maker such as Gates, Aisin, ContiTech (Continental) or Dayco, which supply many carmakers. Choose a kit that includes the belt, tensioner and idler pulleys, and on engines where the water pump is driven by the timing belt, one with a water pump. Replace any seals that leak at the same time, and always follow the engine’s timing procedure.

Get the timing right

Fitting a timing belt one tooth off can damage an interference engine. If you are not confident with timing marks and locking tools, have a professional do the job.

Timing belt and pulleys at the front of an engine
A timing belt kit replaces the belt together with the tensioner and idler pulleys it runs on.

What a timing belt kit includes

  • Timing belt: the toothed rubber belt itself.
  • Tensioner: keeps the belt at the correct tension; often hydraulic or spring-loaded.
  • Idler pulleys: guide the belt. Their bearings wear along with the belt.
  • Water pump (in some kits): on many engines the timing belt drives the pump, so it is replaced at the same time.
  • Sometimes seals, bolts or a thermostat.

Not sure whether your engine has a belt or a chain? See timing belt vs timing chain.

How to choose a timing belt kit

  • Exact fit: match the year, make, model and engine code. Some engines changed belt designs during production.
  • Complete kit: a belt-only replacement leaves old tensioners and idlers that can fail later.
  • Water pump: if your water pump sits behind the timing cover, choose a kit that includes it; the labor overlaps almost entirely.
  • Reputable brand: Gates, Aisin, ContiTech and Dayco are long-established timing component makers, and many supply carmakers directly.
  • Avoid unbranded kits with no clear part numbers or warranty.

Installation tips and common mistakes

  1. Follow the service manual for your engine, including the locking tools it calls for.
  2. Set the engine at top dead center and confirm all timing marks before removing the old belt.
  3. Replace the crankshaft bolt if the manual says it is torque-to-yield.
  4. Fit the new belt with the slack on the tensioner side, then set the tensioner exactly as instructed.
  5. Turn the engine by hand at least two full turns and recheck every timing mark before starting.
  6. Torque all bolts to specification. See how to use a torque wrench correctly.
  7. Fix oil leaks from cam or crank seals; oil ruins new belts.
Mechanic working on a timing belt installation
Lining up the timing marks before and after fitting the new belt is the most important step.

Some engines need a puller or installer for the crank pulley; see harmonic balancer installer tools.

When to replace a timing belt

  • At the interval in your owner’s manual, often 60,000 to 105,000 miles or 5 to 10 years, whichever comes first.
  • If you see cracks, missing teeth, fraying or oil contamination.
  • If you do not know when it was last done.

Warning signs of a failing belt are covered in timing belt failure symptoms.

Frequently asked questions

What is the best timing belt kit brand? +
There is no single best brand. Gates, Aisin, ContiTech and Dayco are established makers; the right choice is a complete kit made for your exact engine.
Should I replace the water pump with the timing belt? +
If the timing belt drives the water pump, usually yes. The labor overlaps, and an old pump can leak or fail and damage the new belt.
Can I replace only the timing belt? +
You can, but old tensioners and idlers often fail before the next belt change. A full kit is usually better value.
How long does a timing belt kit last? +
Usually until the next scheduled belt change, often 60,000 to 105,000 miles.
Is a timing belt replacement a DIY job? +
For experienced home mechanics with the right tools, sometimes. Getting the timing wrong can damage the engine, so many owners use a shop.
